Eight-function Electric Hospital Bed
NO.:000420
Product Model:RH-AD801
Product Size:2120*995*500*940mm
*The Eight Electric Hospital Bed boasts an impressive eight-point adjustment system, allowing caregivers to customize the bed’s position to suit individual patient needs. From the head and foot sections to the overall height, every aspect can be precisely controlled via an intuitive electric control panel.
*The bed prevents falls and ensures patient safety. In addition, the bed’s sturdy frame and sturdy construction provide a stable base that minimizes the risk of accidents.
Features:
- ABShead and foot board – quick and easy to assemble and disassemble
- Remote controller built in railing, for nurse and patient easy control
- Linak engine with angle display on guard rail
- One button chair position
- Hand control manual CPR function
- Bed length can be extended when needed
- Four-piece ABS guardrail
- Bumper wheels
- Nurse controland lock
- With I.Vpole
- With Drainage bag hooks on both sides
- Central brake system with 6″ wheels
- Integrated base with all cable and motor inside, the bed can be washed
- X-ray translucent back part
Technical Parameter :
Model | RH-AD801 |
Overall length (extended) | 2120mm |
Overall length (not extended) | 1920mm |
Overall width | 995mm |
Patient platform length (extended) | 2020mm |
Patient platform length (not extended) | 1820mm |
Patient platform width | 820mm |
Maximum safe load | 250kg |
Back-rest adjustment | 0°-70° |
Knee-rest adjustment | 0°-30° |
Trendelenburg / Reverse trendelenburg | 0°-15° |
Height adjustment | 500-940mm |
Foot-part decline | 0°-90° |
Packing size of wooden case | 207*103*61CM |
N.W. | 185kg |
G.W. | 200kg |
Control panel:
Various positions can be adjusted by nurse control panel, which is set in the outer side of guardrail. It also includes nurse lock for each function.
① Back-rest adjustment
② Knee-rest adjustment
③ Trendelenburg and reverse trendelenburg
④ Height adjustment
⑤ Foot-part decline
⑥ Bed platform extend
⑦ One button chair position
⑧ CPR
⑨ Nurse lock for all funtions
Bed light:
Patient can use the bed light button to turn on the light when getting up at night. This button is set in the inner side of guardrail.
Use of guardrail:
Pull the lock out to lower the side rail (unlock). To secure (lock) pull the side rail up until you hear click
Manual CPR function:
The switch enables the quick release of back part, so that the cardiopulmonary resuscitation can be performed
Move and stop the bed.
Foot step the brake pedal (red) at either side of the table, the table can be locked. Foot step the un-lock pedal (green) at either side of the table, the table can be moved.
Weighing and Alarm Away System
